ZD...
CATHODE
D...
CATHODE
R1 : 330K (3 - 3 - 4 - B - 9)
R2 : 330K (3 - 3 - 4 - B - 9)
R3 : 220
(2 - 2 - 1 - B - 9)
R4 : 47K (7 - 7 - 3 - B)
R5 : 1K
(1 - 0 - 2 - B)
R6 : 1K
(1 - 0 - 2 - B)
R7 : 10K
(1 - 0 - 3 - B)
R8 : 10K
(1 - 0 - 3 - B)
R9 : 10K
(1 - 0 - 3 - B)
R10 : 2K2
(2 - 2 - 2 - B)
R11 : 6K8
(6 - 8 - 2 - B)
R12 : 3K9
(3 - 9 - 2 - B)
5. Resistors
IC1 : 8p
6. IC socket. Watch the
position of the notch!
Construction
D1 :
1N4148
1. Diodes. Watch the polarity !
4. Metal film resistors (1%)
R...
ZD1 : 5V1/0.5W
ZD2 : 24V/1.3W
2. Zenerdiodes. Watch the
polarity !
D2 :
1N4007
D3 :
1N4007
D4 :
1N4007
D5 :
1N4007
3. Diodes. Watch the polarity !
D...
CATHODE
R...
C1 : 100nF
(104)
C2 : 100nF
(104)
7. Capacitors.
c...
