Leds and how to use them
Features
LEDs: 5 x 5 x 5 = 125 LEDs
•
user programmable via USB
•
(creation of animation/scenes)
large amount of user programmable frames
•
frames are separately dimmable
•
4 transition speeds
•
available frames: 3200
•
5 levels LED dimming available
•
no coding skills required
•
regulated power supply: 9VDC
•
Build your 3D led cube and created unlimited 3D effects. The unit
comes standard loaded with effects. Connect to your computer
(USB) and create your own!
It is advised to start with the
mini 3D LED cube MK193.
View the assembly movie of
MK193 as guideline for
assembly of the LEDs.
Expert soldering
skills required!
For software, visit www.vellemanprojects.eu
