Spicer, Tag axle, The new spicer

S21-060B
S23-070B
21,000 lbs. [9,525 kg] – 23,000 lbs. [10,433 kg]
Spicer
®
Tag Axle
The New Spicer
®
Tag Axle
•
The lightest 6x2 package available
when used with Spicer
®
S23-170
single drive axle or the S23-190 single
drive axle
•
Up to 400 lbs. lighter in weight
as compared to conventional
40k tandem 4x4 installation
•
Uses common torque rod brackets
and axle seats for air-ride suspensions
•
Patented* removable cover plate and
spindle plugs allow for conversion to a
full tandem without housing replacement
or removal
•
Uses Spicer standard 21k GAWR rear
drive axle housing from 40k tandem
or 23k GAWR rear drive axle from
46k tandem
•
Sealed standard housings allow options
for future use
•
Common wheel-end configuration to
support a wide variety of brake and
hub options
•
Warranty coverage equivalent to Spicer
drive axles specified in 6x2 applications
* U.S. Patents
US 7232398 B2
US 7410440 B2
All applications must be approved by the Application Engineering Department. Specifications and/or design are subject to change without notice or obligation.
Printed in USA AXSL-0490 07/09
For spec‘ing or service assistance, call 1-877-777-5360 or visit our website at www.dana.com
