Spicer Carrier Design Modifications to Dana 34-44K - Manual (Page 5)

Capscrew & Stud Fastener Locations for
Dana 34-44,000 lbs Tandem Axle Models – After 6/3/02*
*These are the fastener configurations when all changes are completely implemented. Changes to the new design
carriers are being done as a running change. GM models require special double-ended capscrews.
RA344, 404, 405,
RS344, 404, 405, 454,
RD404, 405, 454,
RSP40, 41, RDP40, 41
C C
B
B B
HEAD TO HOUSING
B B
B
C C
For spec’ing or service assistance, call 1-800- 24 hours a day, 7 days a week,
(Mexico: 8-332-1515). Or visit our web site at: wwwVSLFHUSDUWV.com
Dana Corporation
ABIB-0210r1 Copyright Dana Corporation, 2002 Commercial Vehicle Axle Division
August 2002 All Rights Reserved. P.O. Box
Printed in U.S.A. www.dana.com 7ROHGR2KLR
A
A
A
A
A
A
A
A
A
A A
A A
A A
A A
DA344, 404, 405,
DS344, 404, 405, 454,
DD404, 405, 454,
DSP40, 41, DDP40, 41
DST40, DST41
C
B
B
HEAD TO HOUSING
B B
B
C C
A – 127641 Studs & 127567 Nuts
B – 130836 Capscrews – Short (45mm)
C – 130837 Capscrews – Long (70mm)
D – 130877 Flat Washers – All Locations
A - Studs to Extend 1-11/16 (43mm) from “Face” of housing.
DSH40, DDH40
DSH44, DDH44
C
HEAD TO HOUSING
C C
RSH40, RDH40
RSH44, RDH44
C C
B
B B
HEAD TO HOUSING
B B
B
C C
VIEW – LOCATION OF FASTENERS ARE VIEWED AS IF
INSTALLING DIFFERENTIAL INTO THE AXLE HOUSING.
5
