SPICER PART NAMES,
TYPES & NUMBERS
®
OLD STYLE: Identify the part by the 2nd (center) number set (as shown on the previous page) of the complete part number. In the complete part
number, with the exception of Journal & Bearing Kits, Support Bearing Assemblies, Driveshaft Assemblies, and Tubing, the:
1st Number Set — Indicates the Joint Series
2nd Number Set— Indicates the Part Type
3rd Number Set— Indicates the Serial Number
4th Number Set— Indicates Additional Information
J300P SECTION 9
Miscellaneous Parts
•
bolts
•
nuts
•
dust caps
•
balance weights
•
keys
• tube deadeners
• snap rings
J300P SECTION 2
Flange Yokes
(Part Type Number Set = 2)
J300P SECTION 5
Tube Yokes Center Yokes &
(Part Type Number Center Plates
Set = 26 or 28) (Part Type Number
Set = 26)
J300P SECTION 7 J300P SECTION 7
Tube Shafts Midship Tube Shafts
(Part Type Number Set = 40 or 42) (Part Type Number Set = 53 or 54)
Rectangular Circular
J300P SECTION 1
Companion Flanges
(Part Type Number Set = 1)
J300P SECTION 3
Slip Yokes Splined Sleeves
(Part Type Number Set = 3) (Part Type Number = Set 55)
J300P SECTION 4
End Yokes
(Part Type Number Set = 4)
J300P SECTION 6
Tubing Yoke & Tube Assemblies
(Part Type Number Set = (Part Type Number Set = 27)
30 or 32)
J300P SECTION 8
Yoke Shafts
(Part Type Number Set = 82)
