Specifications:
MODEL
GAWR (LBS.)
NOMINAL GCW (LBS.)*
RATIOS
0
9
.
0
1
,
7
9
.
9
,
1
5
.
9
,
5
5
.
8
,
5
7
.
7
,
8
4
.
7
,
0
3
.
7
,
5
6
.
6
,
4
3
.
6
,
8
9
.
5
,
0
7
.
5
,
4
4
.
5
,
9
1
.
5
,
9
9
.
4
,
5
7
.
4
0
0
0
,
0
4
2
0
0
0
,
6
4
P
0
9
5
-
6
4
D
D52-590P
52,000
240,000
D60-590P
60,000
240,000
D70-590P
70,000
240,000
Nomenclature:
A full range of available options for optimal operation
and durability with less required maintenance.
•
Driver-controlled wheel differential lock for maximum
traction. Available on both forward and rear axle.
•
Wheel differential lock feature can be field retrofitted
throughout the life of the vehicle.
•
Carrier integrated retarder mount means more drivetrain
options with increased strength, brake performance, and
reduced complexity.
•
Wide-track axles for maximum stability.
•
Patented axle breather design allows unrestricted air flow
– a no maintenance feature.
•
Integral welded suspension brackets for increased strength
and durability.
D 52 - 5 9 0 D
D - Forward Tandem Axle
w/Interaxle Differential
R - Rear Tandem Axle
GAWR (x 1000 lbs.)
Gear Type:
1 - Standard Single Reduction
5 - Helical Double Reduction
Head Assembly Series
Design Level
Options:
D - Differential Lock
R - Retarder Ready
P - Optional Lube Pump
W - Wide-track
Extra wide face-width gearing
provides greater strength for
increased durability at higher
loads.
Larger wheel differential gearing
means maximum strength and
reliability.
* Varies by duty cycle.
Patented, on-demand lube pump
for optimal spin-out protection
without the added heat.
Spicer
®
D590 Series Double Reduction
Tandem Drive Axles
All applications must be approved by the Application Engineering Department. Specifications and/or design are subject to change without notice or obligation.
Printed in USA AXSL-0484 01/07
For spec‘ing or service assistance, call 1-877-777-5360 or visit our website at www.dana.com
