Spicer Drive Axles Illustrated Parts List All Wheel 4 x 4 Drive System - Manual (Page 7)

7
Qty.
Item per 190S4 230S4 300S4
No. Part Name Axle 220S4 260S4 350S4
26 Side Pinion Thrust Washer 4 27810 86781 86781
27 Spider 1 38289 86778 86778
28 Pilot Bearing 1 129175 126187 126187
29 Bearing Cone (Inner) 1 85439 14218 14218
Bearing Cone (Outer) 1 110846 14218 14218
30 Spacer Washer 1 - 78904 78904
31 Bearing Spacer AR
See separate listing on page 9
32 Bearing Cup (Inner) 1 14217 14217 14217
Bearing Cup (Outer) 1 35502 14217 14217
33 Bearing Cage Shim .003" AR 45461 45461 45461
.005" 62829 62829 62829
.010" 45462 45462 45462
.020" 62830 62830 62830
.030" 45463 45463 45463
34 Bearing Cage & Cup Assy
Includes Item 32 (Cage 78932) 1 78914 78914
Ratios 3.55-3.70 (Cage 110730)
-
1 110731
Ratios all others (Cage 110732)
- -
1 110733 - -
35 Cap Screw 6 62158 62158 62158
36 Lockwashers 6 37207 37207 37207
37 Helical Gear 1 111310 98390 98390
38 Helical Gear Spacer
Ratios 3.55-3.70 1 111316
Ratios all others
- -
1 111311 - -
39 Outer Pinion Support Bearing & Race 1 111314 78916 78916
40 Snap Ring 1 111315 78937 78937
41 Slotted Nut 1 118854 119353 119353
42 Roll Pin 1 118855 118807 118807
43 Input Shaft Bearing Cup (Outer) 1 98388 98385 98385
Input Shaft Bearing Cup (Inner) 1 90951 98388 98388 .
44 Input Shaft Bearing Cone (Outer) 1 91136 98384 98384
Input Shaft Bearing Cone (Inner) 1 91136 98387 98387
45 Input Shaft & Helical Gear 1 111384 - -
46 Helical Gear 1 98389 98389
47 Power Divider Cover & Plug Assy 1 113602
(Cover 111300) Includes Items 51,52
- -
Power Divider Cover (Cover 111375-NSS) Includes 39-40, 43 1 - 111368 111368
48 Carrier Cover Cap Screw
Medium 4 90069
Long
- -
4 12063 -
12Pt
-
81855 - -
Medium 1
- 90069 90069
Long 1 - 9309 9309
49 Lockwashers 9 90417 90417 90417
50 Dowel Pin 2 7641 7641 7841
51 Pipe Plug 2 90325
- -
52 Expansion Plug 1 9797
- -
53 Lockout Cover Plate 1 111673 - -
54 Cap Screw 2 20807
- -
55 Lockwashers 2 90415 - -
56 Pump Cover Plate 1 111674
- -
57 Cap Screw 4 79363
- -
58 Lockwashers 4 90419
- -
59 Input Shaft (Note 4) 1
- 98393 98393
Note 4: 98393 Being Replaced By 129315 Input Shaft w/(Metric Thread), 126155 Nut (Metric), 126242 Washer
