Spicer 15130 User Manual
Spicer, Drive axles

Spicer
®
Drive Axles
P/N: SHAIS194B
INFORMATION SHEET – GREASEABLE PINION SEAL ASSEMBLY PARTS
Affected Models:
15130 Drive Axles
Shown below are the individual parts that make up the 128995X pinion seal assembly kit. When installing or replacing the
individual seals or grease fitting be sure to take proper care so as to not damage the seal surfaces or mis thread the
fitting.
Copyright Dana Limited, 2013
Dana Aftermarket Group
SHAIS194B MAR 2013
All Rights Reserved.
P.O. Box 321
Printed in U.S.A.
Dana Limited
Toledo, OH 43697-0321
128996 - Bearing Seal Cap
500174-1 Grease Fitting
126885 - Seal
126883 - Seal
126884 - Seal
