INFORMATION SHEET SHAIS180R1 – TPCS Air Seal Replacement
Bill of Material for Spicer Service Kit p/n 513417
Part Number Description Qty Notes
676551 Air Seal 2 Replaces Air Seal Assembly p/n 673305
673362 Retainer Screws (8x32) 3
676562 Retainer Washers 3
673303 Installation Guard 1
599963 Hub O-Ring Seal 2 Required in hubs w/ existing o-ring grooves
SHAIS180 Information Sheet 1
Related p/n associated with air seal replacement
Part Number Description Notes
676575 Air seal driver Installs both inner and outer air seals in the hub
J-8092 Universal driver handle Available from Kent Moore (ph 800-345-2233)
673301 Hub oil seal * see note Replace when removing hub / replacing air seals
129280 Hub oil seal driver
129442 Bearing centering tool
800T Oil seal driver handle
NOTE: Replacement of the oil seal is recommended when replacing the air seal or removing the hub for any
reason.
