Spicer New Dana Spicer Steer and Trailer Axle Hubcaps for Oil Application - Manual (Page 2)

Parts Listing for Dana Steer Axle & Trailer Axle Hubcap Parts
A. B. 1.
Items C & D – Hubcap Bolts &
Lockwashers – Not Illustrated
Description Vent Cap Design
1 977123 Hubcap Kit 4.50" Oil
1 977125 Hubcap Kit 5.50" Oil
1 977124 Hubcap Kit 4.50" Oil
1 977126 Hubcap Kit 5.50" Oil
A 976630 Vent Plug n/a Oil Blue - LMS Included w/ all hubcap kits
A 976764 Vent Plug n/a Oil Black Included w/ all hubcap kits
B 977147 Gasket 4.50" ----- ----- Included w/ all hubcap kits
B 977148 Gasket 5.50" ----- ----- Included w/ all hubcap kits
C 976996 Bolts (qty 6) n/a ----- ----- Included w/ all hubcap kits
Notes Type Hubcap
BC
Dimension
Hub Cap - Non LMS
Black
LMS Hub Cap - Blue
*Note: At this time the LMS Hubcaps for grease applications has not been released.
Dana Kit P/N
Item
No.
SPICER HUBCAP PART NUMBERS - STEER AXLES
Description Vent Cap Design
1 M10HK209 Hubcap Kit 5.50"
Syn
Grease
LMS - Vented
Spicer logo, "D" series axles
(replaces P/N: EH969137)
M10HK199 Hubcap Kit 5.50" Oil LMS Spicer logo, "D" series axles
1 M10HK213 Hubcap Kit 6.75" Oil LMS Spicer logo, "P" series axles
1 M10HK210 Hubcap Kit 6.75" Syn Grease LMS - Vented
Spicer logo, "P" series axles
(replaces P/N: EH969138)
B M10HG138 Gasket 6.75" ----- ----- Included w/ all hubcap kits
B M10HG108 Gasket 5.50" ----- -----
Included w/ all hubcap kits
(replaces P/N: EH969143)
C M10HM182 Bolts (qty 6) ----- ----- ----- Included w/ all hubcap kits
D M10HN216 Lockwashers (6) ----- ----- ----- Included w/ all hubcap kits
Notes
Item
No.
Dana Kit P/N
BC
Dimension
Type Hubcap
SPICER HUBCAP PART NUMBERS - TRAILER AXLES
For spec’ing or service assistance, call 1-800- 24 hours a day, 7 days a week
Or visit our web site at: http://www.VSLFHUSDUWV.com
