Spicer 2008 Spicer Universal Joint Kits and Center Bearings - Manual (Page 274)

259
K350
MSC
Center Bearing Detail
Parts not sold separately — Shown for informational purposes only
B C Center Bearing Major Parts Retainers
Center Front Rear
Bearing Centerline Bracket Rubber Bearing & Slinger Slinger
Assy Part To Mounting Bracket Part Cushion Retainer Part Part
Number Surface Width Number Part Nbr. Assy. Number Number Bottom Top
A = 1.181 Bearing I.D. D = 1.500 (2) Threaded Holes
210527X 3.560 .630 210580X 550735 230318 ~ ~ ~
A = 1.181 Bearing I.D. D = 5.880 Bolt Hole/Stud Size = .630 (H)
211590-1X 1.940 1.450 5007512 231695 211554X 231696 ~ 3-95-139 ~
A = 1.260 Bearing I.D. D = 5.880 Bolt Hole/Stud Size = .630 (H)
211431X 1.940 1.450 231694 231695 211409-1X 231696 ~ 3-95-139 ~
A = 1.378 Bearing I.D. D = 6.620 Bolt Hole/Stud Size = .560 (H)
211175X 2.250 1.726 231285 231212 210086X 231286 231256 3-95-99 ~
211819-1X 2.250 1.726 231285 232181 210086-3X 231286 231256 3-95-99 ~
Part has been discontinued
A = 1.574 Bearing I.D. D = 6.620 Bolt Hole/Stud Size = .560 (H)
211499X 2.250 1.726 231285 231212 210865-1X 231286 231834 3-95-99 ~
211748-3X 2.250 1.726 231285 232181 210865-1X 231286 231834 3-95-99 ~
Part has been discontinued
212053-1X 2.250 1.726 231285 231212 210865-1X 231286 ~ 3-95-99 ~
Style 10
Parts not sold separately — Shown for informational purposes only
B C Center Bearing Major Parts Retainers
Center Front Rear
Bearing Centerline Bracket Rubber Bearing & Slinger Slinger
Assy Part To Mounting Bracket Part Cushion Retainer Part Part
Number Surface Width Number Part Nbr. Assy. Number Number Bottom Top
Style 11
