Spicer Crate Axle Sheet - Manual (Page 2)

crate axles
Ring Gear Size Torque limit @ input GAWR GVW GCW
Model Location inch ft.-lbs. lbs. lbs. lbs.
Dana 30 ™ Front 7.30 1450 2800 5700 8000
Dana 44 ™ Rear 8.90 1930 3570 5700 8500
Dana 44 ™ Front 8.50 1930 3360 5700 8000
Dana 60 ™ Rear 9.75 2400 5760 8200 17100
Dana 60 ™ Front 10.10 2785 7350 16000 30000
Dana 70 ™ Rear 10.50 2600 8580 9900 18000
Dana 70 ™ Front 10.75 3450 8400 19500 26000
Dana 80 ™ Rear 11.25 3000 10100 14000 30000
Note: These ratings are general guidelines. Actual load rating and torque limit will vary by application and duty cycle.
Spicer ® Light Axle Ratings:
Ratios:
30 Front 44 Rear 44 Front 60 Rear 60 Front 70 Rear 70 Front 80 Rear
3.73 X A X A X X X X
4.10 X A X A X X X X
4.56 X X X X X X X X
4.88 X X X X X X X X
5.13 X X X X X X X X
GAWR is Gross Axle Weight Rating. Maximum distributed weight an axle can support.
GVW is Gross Vehicle Weight Rating. Maximum allowable weight of vehicle when fully loaded.
GCW is Gross Combined (vehicle and trailer) Weight Rating. Maximum combined mass of vehicle and trailer when both are fully loaded.
Torque limit @ input (ft.-lbs.) is the maximum recommended driveline torque input into the axle flange/yoke at pinion.
Planned Ratios
mum allo
cle and trailer) Weight
(ft.-lbs.) is the maximum recomm
hicle wh
ng. Maximum combine
mended driveline torque inpu ecomm
vehicle and trailer whe
ut into the axle flange/yoke at pinio p
are fully loaded.
on. pinio
For more information, please contact your local Spicer products sales representative or visit our website at www.crateaxle.com.
A = Gear set is available. X = Gear set is planned for future release.
