Spicer Vibra-Damp TM Rubber Element Shafts - Manual

Information Required For Making a Preliminary
Resilient Shaft Recommendation
Company Name
Address
Telephone number with area code
Signature Date
* A. Engine Angle * G. Engine – Torque (Max.)
* B. True U-Joint Angle (3° Max.) * H. Idle Speed (RPM)
* C. True U-Joint Angle (3° Max.) * I. Engine – Max. & Min. (RPM)
* D. Minimum Length (Installed) * J. No. of Cylinders & Cycle of Engine
* E. Engine – Bolt and Pilot Info. * K. WR 2 of Engine (Include Flywheel) lb.ft. 2
* F. Dyno – Bolt & Pilot Info. * L. WR
2
of Dyno lb.ft.
2
* M. Make of Dyno
Mail or Fax Completed form to: * N. Duty Cycle of Testing (Approx.)
Dana Aftermarket Group
Dana Holding Corporation
PO Box 321 * Required Information
Toledo, Ohio 43697-0321
(419) 866-3951
Fax: (800) 332-6124
www2.dana.com\expert
3701-3 6/12
Vibra-Damp TM
Rubber Element Shafts
