Spicer Ring and Pinion Tooth Contact Pattern Information User Manual
Page 3
3
SHAIS168B – Ring and Pinion Contact Pattern Information
Copyright Dana Limited, 2013
Dana Aftermarket Group
SHAIS168B FEB 2013
All Rights Reserved.
P.O. Box 321
Printed in U.S.A.
Dana Limited
Toledo, OH 43697-0321
Refer to this illustration for proper ring gear nomenclature.
Toe
Root
Top land
Heel
Face
Tooth Depth
