Has you covered, Drive axles, Spicer

From Deep-Drop Axles
To Innovative All-Wheel
Drive Systems, Dana
Has You Covered.
4. Spicer
®
All-Wheel
Drive System
The distinctive transfer
gearing design used by
Spicer
®
all-wheel drive
systems divides power in
the rear axle, eliminating the
conventional transfer case
and related componentry.
This reduces initial cost
and weight for increased
payload capacity and fuel
efficiency, making Spicer
®
the cost-effective choice.
With fewer components,
installation and operation
are quick and easy, and
maintenance time is
significantly reduced.
Available in 4x4 or
6x6 configurations.
5. Spicer
®
LMS
®
Wheel
End System
The unique LMS
®
hub
design eliminates wheel
bearing adjustment and
installation variables that
cause excessive end play
and lead to premature wheel
seal failures. Premium oil
bath seals, combined with
precision-manufactured
bearing spacers and special
tolerance bearings, serve as
your best defense against
costly brake replacements
and downtime. Aluminum
or iron hubs are available in
a wide range of axle ratings.
6. Spicer
®
LMS
®
Hubcap
The perfect partner to
the Spicer
®
LMS
®
hub,
this unique hubcap and
vent system is designed
to simplify maintenance,
prevent contamination,
and ensure the longevity
of wheel-end components.
Made from a corrosion-
resistant material that is
lighter and significantly
stronger than aluminum,
these hubcaps will not corrode
from road salt or chemicals.
A patent-pending containment
exclusion system prohibits
water entry from submerged
water or high-pressure spray.
7. Spicer
®
TPCS
(Tire Pressure
Control System)
TPCS allows you to select
your tire pressure right from
the cab to match the terrain
and increase vehicle mobility
over soft soil, sand, and mud.
TPCS also automatically
maintains the proper tire
pressure for vehicle speed
to extend tread life and
improve fuel economy.
Use of optimal tire pressure
reduces costly punctures
and tread chunk-out.
Bendix
®
brand foundation
brake systems are brought
to you by Bendix Spicer
Foundation Brake, LLC,
a Bendix Commercial
Vehicle Systems and
Dana Holding Corporation
joint venture. Bendix
®
air
disc brakes offer safety,
performance, and peace of
mind under the toughest
driving conditions. Bendix
®
air disc brake technology
dramatically improves in-line
braking stability for straighter
stops and shorter stopping
1. Spicer
®
Steer Axles
Spicer
®
steer axles combine
proven durability with
flexible options that allow
you to optimize stopping
distance, performance,
and life cycle cost for your
application. Compatible
with the latest air disc and
air drum brake technology,
these steer axles offer
a patented “Power
Rib” design for superior
durability and deflection
characteristics. The D-2000F
steer axle offers a 5” drop
beam option and up to
a 50 degree turn angle to
provide a lower chassis
suspension profile and
added maneuverability.
The D-2000F 3.5” and 5”
drop also offers Dana’s
patented in-line dual
draw keys for improved
camber alignment for
reduced tire wear.
2. Spicer Life
®
Series
Driveshafts and
Universal Joints
Designed for demanding
high-torque, high-horsepow-
er applications, Spicer Life
®
driveshafts set the standard
for heavy-duty driveshaft
performance with a more
advantageous weight-to-
length ratio, small swing
diameter, and improved
balance and stiffness. Quick
Disconnect
™
end yokes
control deflection, improve
overall strength, and reduce
maintenance. Spicer Life
XL
®
universal joints feature
new seals for extended
lubrication intervals and new
bearing thrust washers that
eliminate metal-to-metal
contact to lower operating
temperature.
Available in three series,
serving 21,000 to 30,000 lb.,
46,000 to 50,000 lb., and
52,000 to 60,000 lb. GAWR
applications, Spicer
®
single
and tandem drive axles
offer the strength, durability,
and reliability required for
demanding use. Features
such as extra-wide face-
width gearing, large wheel
differential gearing, and
forged, heat-treated steel
differential cases ensure
maximum strength and
high power density, while
the high-capacity gearing
and bearing system provides
durability and reliability
with higher-horsepower/
torque engines.
With more than 25 years of experience in the fire industry,
Dana offers a comprehensive product system noted for
its proven performance, ease of use, low maintenance
features, and cost efficiency.
3. Spicer
®
Single and Tandem Drive Axles
distances – including superior
performance on downhill
grades. Also available are
Bendix
®
wide drum brakes,
combining proprietary
linings with advanced shoe
construction and geometry
control for reliability, durability,
longer life, and superior
performance. Bendix
®
brake
chambers and slack adjustors
provide a short chamber
stroke without dragging for
better braking performance.
8. Bendix
®
Foundation Brake Systems
Axle
Model
Max.
GAW
lbs.
(kg)
Max.
GCW
lbs. HWY
(kg)
Ratios
Body Diameter
in. (mm)
Number of
Splines
Spline Diameter
in. (mm)
Axle Shaft
Ring Gear
Diameter
in. (mm)
Box Section
Width
Box Section
Height
Wall Thickness
at Spring Seat
Axle Housing
LMS
®
Hub
TPCS
(Tire Pressure
Control System)
Differential Lock
Electromagnetic
Retarder
Single Reduction Single Drive Axles
Spicer
®
Drive Axles
Ratings
3
4
5
6
7
8
1
2
No Spin
S23-170
23,000
(10,443)
100,000
(45,359)
3.07, 3.21, 3.42, 3.58,
3.73, 3.91, 4.10, 4.30,
4.56, 4.78, 5.25, 5.38,
5.57, 6.14, 6.83, 7.17
2.06
(52)
46
2.35
(60)
17.7
(450)
4.61
(117)
5.24
(133)
0.43
(11)
S25-170
S26-190
S30-190
232S4*
232D4*
262S4*
262D4*
S30-590
S35-590
DSH44
D46-170
D50-170
D52-190P
DS4636-P*
DD4636-P*
DS5216-P*
DD5216-P*
25,000
(11,340)
26,000
(11,793)
30,000
(13,608)
23,000
(10,443)
26,000
(11,793)
30,000
(13,608)
35,000
(15,876)
44,000
(19,958)
46,000
(20,865)
50,000
(22,680)
52,000
(23,587)
46,000
(20,865)
52,000
(23,587)
100,000
(45,359)
125,000
(56,699)
125,000
(56,699)
85,000
(38,555)
85,000
(38,555)
125,000
(56,699)
125,000
(56,699)
110,000
(49,887)
160,000
(72,575)
160,000
(72,575)
225,000
(102,058)
160,000
(72,575)
160,000
(72,575)
3.42, 3.58, 3.73, 3.91,
4.10, 4.30, 4.56, 4.78,
5.25, 5.38, 5.57, 6.14,
6.83, 7.17
3.42, 3.58, 3.73, 3.91,
4.10, 4.30, 4.56, 4.78,
5.25, 5.38, 5.57, 6.14,
6.83, 7.17, 7.83
3.55, 3.70, 3.90, 4.11,
4.33, 4.56, 4.88, 5.43,
6.17
4.75, 4.99, 5.19, 5.44,
5.70, 5.98, 6.34, 6.65,
7.30, 7.48, 7.75, 8.55,
9.51, 9.97, 10.90
3.36, 3.55, 3.70, 3.90,
4.11, 4.33, 4.63, 4.88,
5.29, 5.57, 6.17, 6.50, 7.17
3.07, 3.21, 3.42, 3.58,
3.73, 3.91, 4.10, 4.30,
4.56, 4.78, 5.25, 5.38,
5.57, 6.14, 6.83, 7.17
3.42, 3.58, 3.73, 3.91,
4.10, 4.30, 4.56, 4.78,
5.25, 5.38, 5.57, 6.14,
6.83, 7.17
3.55, 3.70, 3.90, 4.11,
4.33, 4.56, 4.88,
5.43, 6.17
2.25
(57)
2.25
(57)
2.25
(57)
2.06
(52)
2.25
(57)
2.25
(57)
2.25
(57)
1.88
(48)
2.06
(52)
2.06
(52)
2.25
(57)
2.06
(52)
2.25
(57)
46
46
46
36
36
46
46
41
46
46
46
36
36
2.35
(60)
2.35
(60)
2.35
(60)
2.31
(58.7)
2.31
(58.7)
2.35
(60)
2.35
(60)
2.10
(53)
2.35
(60)
2.35
(60)
2.35
(60)
2.31
(58.7)
2.31
(58.7)
17.7
(450)
18.5
(470)
18.5
(470)
18.0
(457)
18.0
(457)
18.5
(470)
18.5
(470)
15.75
(400)
17.7
(450)
17.7
(450)
18.5
(470)
18.0
(457)
18.0
(457)
4.61
(117)
4.61
(117)
5.31
(135)
4.61
(117)
5.31
(135)
5.31
(135)
5.63
(143)
4.61
(117)
4.61
(117)
4.61
(117)
5.31
(135)
4.61
(117)
5.31
(135)
5.24
(133)
5.24
(133)
5.91
(150)
5.24
(133)
5.91
(150)
5.91
(150)
6.73
(171)
5.24
(133)
5.24
(133)
5.24
(133)
5.91
(150)
5.24
(133)
5.91
(150)
0.50
(13)
0.63
(16)
0.63
(16)
0.56
(14)
0.63
(16)
0.63
(16)
0.87
(22)
0.50
(13)
0.50
(13)
0.63
(16)
0.63
(16)
0.56
(14)
0.63
(16)
Double Reduction Single Drive Axles
Single Reduction Tandem Drive Axles
*Also available in two speed
S23-190
23,000
(10,443)
125,000
(56,699)
2.53, 2.69, 2.87, 2.93,
3.07, 3.21, 3.42, 3.58, 3.73,
3.91, 4.10, 4.30, 4.56, 4.78,
5.25, 5.38, 5.57, 6.14, 6.83,
7.17, 7.83
2.06
(52)
46
2.35
(60)
18.5
(470)
4.61
(117)
5.24
(133)
0.50
(13)
= Product is available.
