16120 STANDARD SPIRAL GEAR SETS
RATIO TOOTH
COMBO
SERVICE
GEAR
SET P/N
15"
GEAR
(NSS)
ENGLISH
THREADS
PINION (NSS)
4.62
37/8
98124*
50186
50187
4.88
39/8
98125*
50188
50189
5.57
39/7
98126*
50190
50191
6.14
43/7
98127*
50192
50193
6.50
39/6
98128*
50194
48430
7.17
43/6
98129*
50196
50197
7.60
38/5
98130*
48701
48702
16120 RH SPIRAL GEAR SETS
RATIO TOOTH
COMBO
SERVICE
GEAR
SET P/N
15"
GEAR
(NSS)
ENGLISH
THREADS
PINION (NSS)
4.62
37/8
98773*
50174
79267
4.88
39/8
98774*
50176
84383
5.57
39/7
99686**
50178
99684
6.14
43/7
98775*
50180
79689
6.50
39/6
98776*
50182
93661
7.17
43/6
98777**
50184
90986
7.60
N/A
N/A
N/A
16130 STANDARD SPIRAL GEAR SETS
RATIO TOOTH
COMBO
SERVICE
GEAR
SET P/N
15"
GEAR
(NSS)
METRIC
THREADS
PINION (NSS)
4.62
37/8
218832
50186
129241
4.88
39/8
218833
50188
129242
5.57
39/7
218834
50190
129243
6.14
43/7
218835
50192
129244
6.50
39/6
218836
50194
129245
7.17
43/6
218837
50196
129246
7.60
38/5
218838
48701
129247
16120 MODEL
.514 91617
.526 91633
.515 91618
.527 91637
.516 91619
.528 91641
.517 91620
.529 91645
.518 91621
.530 91649
.519 91622
.531 91653
.520 91623
.532 91657
.521 91624
.533 91661
.522 91625
.534 91665
.523 91627
.535 91667
.524 91629
.536 91669
.525 91631
.537 91671
16130 MODEL
.634 91511
.635 91513
.636 91515
.637 91519
.638 91523
.639 91527
.640 91531
.641 91535
.643 91539
.644 91541
.645 91542
.646 91543
PINION SPLINE: 10 Straight 1.75"
* Obsolete - Replace with 16130 Gear Set & New Yoke Assy
** Obsolete - No Replacement
PINION SPLINE: 34 Involute 1.75"
PINION BEARING SPACERS
