HAXL-PNI-17
GENUINE SPICER
®
BEARING CUP & CONE
CHANGES IN D170/D190 FAMILY AXLES
PART NUMBER INFORMATION
DATE:
1/10/2013 -
REVISED
TO:
All Dana Aftermarket Group Spicer
®
Heavy Axle Customers
Affected Models: D/R170, D/R190, D/R590, S170, S190, S590
In order to meet more demanding application and performance expectations, Dana is pleased to
announce a product design change in the models listed above. Dana began implementing the use of the
new design, case hardened carrier’s bearings in production axles in February 2012.
The change to new bearings will impact service kits in a variety of ways. The part number changes have
been outlined below to minimize any potential mixing of bearing parts from different suppliers.
•
Bearings are manufactured and used in sets to maximize full life of the product
•
NOT using SPECIFIED bearings in Dana carriers can create potential noise issues or lead to premature
bearing failures and affect the warranty of product
•
Mixing of bearing cups and cones can create potential noise issues or lead to premature bearing failures
•
New and Old bearing cones and cups are manufactured by different suppliers
•
Superseding OLD individual part numbers directly to the NEW individual part numbers could lead to mixing
of parts that could lead to potential failures.
DO NOT MIX CONES AND CUPS MANUFACURED BY
DIFFERENT SUPPLIERS
• Spicer
®
service kit contents will always contain mating cones and cups
SPICER
®
GENUINE BEARING KITS:
o
Service kit bill of material changes will be done on a running basis.
o
The bill of materials will begin changing in late May 2012.
Dana
Part-No.
Description
Model
Ratios
514011
Bearing
Kit
D170D
all
ratios
514012
Bearing Kit
D190, D190D, D590, D590D
all ratios
514238
Bearing
Kit
D170 all
ratios
514013
Bearing
Kit
R170,
S170
ratios
2.69-3.91
514014
Bearing
Kit
R170,
S170
ratios
4.10-7.17
514015
Bearing
Kit
R170D,
S170D
ratios
2.53-3.91
514015
Bearing Kit
R190, R190D, S190, S190D
ratios 2.53-4.78
514016
Bearing Kit
R190, R190D, S190, S190D
ratios 5.25-7.83
514240
Bearing
Kit
R170D,
S170D ratios
4.10-7.17
