Spicer Carrier-To-Housing Joint Leak User Manual

Page 6

8. Install new fasteners supplied in kit and run them down with an impact gun in a crisscross pattern.

9. Most ½” drive impact guns will put out a maximum torque of 250-300 ft. lbs. Check at least one capscrew to verify that

your impact gun is putting out a minimum of 250 ft. lbs.

10. Clean axle shaft flanges and wheel hub surfaces and install new axle shaft gasket.

11. Reinstall the axle shaft, washers and nuts, torque to spec.

12.

Reconnect IAD shift cylinder airline.

13.

Reinstall the driveline.

14. Remove fill plug from housing cover and refill the housing using the same lubricant that was removed. If needed, add

lube and fill until level with the bottom of the fill hole.

For spec’ing or service assistance, call 1-800

-621-8084 24 hours a day, 7 days a week.

Or visit our web site at:

http://www.

spicerparts.com

Dana Corporation

SHAIS135B

Heavy Vehicle Technologies and Systems Service

January 2008

P.O. Box

321

Printed in U.S.A.

www.dana.com/

Toledo, Ohio 43697-0321

Model Series

Dana Part-No. Fastener Location

Class

Size

lbs-ft

N.m

D/R344, 404

127567

Carrier - to - Housing Nut

M16x1.5

250-300

312-366

130158

Carrier - to - Housing Capscrew

12.9

M16x2

250-300

312-366

Torque Specification Chart - (Carrier - to - Housing)
