Application worksheet – Renata SA 3V Lithium Coin Cells - DESIGNER'S GUIDE User Manual
Page 50
50
www.renata.com
Application Worksheet
Temperature / Humidity
Please submit the temperature profiles to which your application will be typically exposed.
For a precise performance evaluation, please indicate exactly how long the application will be exposed
to each of the following temperatures:
Temperature
<0°C
0°-20°C
20°C
25°C
30°C
35°C
40°C
45°C
days per year
Temperature
50°C
55°C
60°C
65°C
70°C
75°C
80°C
85°C
days per year
Temperature profile:
°C max.
°C min.
°C mean
Humidity:
% RH max.
% RH min.
New project:
yes
no
Project name:
End customer:
Qty. pre-series: pcs. Qty. 1st series pcs.
Qty. P.A.: pcs. / year
Target price: per 100 pcs.
USD
EUR
Dimensions / Weight / Mounting Mode
Operation Requirements
Specific Project Information
Product description
Remarks
Dimensions:
Max. diameter
mm
Max. height
mm
Weight:
Max. weight
g
Mounting Mode:
Plain cell; With soldering tags
horizontal or
vertical
In combination with a battery holder
Mounted on SMT board
Mounted on through-hole board.
Provide a detailed sketch for specific board layouts
Expected operating life:
years
Storage period: years
