Encapsulated batteries, For plug-in, Power modules) – Renata SA 3V Lithium Coin Cells - DESIGNER'S GUIDE User Manual
Page 35
34
35
the
swiss
power source
For plug-in
Encapsulated Batteries
(Power Modules)
Versions for horizontal mounting, without decoupling diodes.
Model
Dimensions
Weight
Nominal Nominal
Standard Max. cont. Part.No.*
(mm)
Voltage Capacity
Current
Current
A
B
C
D
(g)
(V)
(mAh)
(mA)
(mA)
175-0B
22
8
17.8
15.3
6.5
3
235
0.4
3.0
700041
1000-0B
30
10
25.4
22.9
15
3
950
1.0
2.5
700033
*Packaging: Industrial Bulk (IB-Trays)
