Renata SA 329 - Manual

329
SR731SW
Watch Battery OEM
Swiss Made
Rev. 329MF_OEM.02 2010/11
Renata SA Tel. +41 (0)61 975 75 75 [email protected]
CH-4452 Itingen/Switzerland Fax. +41 (0)61 975 75 95 www.renata.com
Technical Data Sheet
Specifications
Chemical system Zinc / Monovalent Silver Oxide, low drain
Nominal Voltage 1,55 V
Capacity 37 mAh, Discharge over 25,5 kΩ at 20°C to 1,2 V
Operating Temperature 0°C – 60°C
Self Discharge Less than 5% per year at 20°C
Weight ~0,58 g
Dimensions
(according IEC 60086-3)
Diameter
Height 7,90 mm (0,311“)
3,10 mm (0,122“)
Discharge Curve
Constant Load
Starting Drain
Temperature 25,5 kΩ
61,2 µA
20°C
Information and contents in this data sheet are for reference purpose only. They do not constitute any warranty or representation
and are subject to change without notice. For most current information and further details, please contact your Renata representative
For safety related information please consult the PSDS document related to that product or product family.
min. ∅ 3,5
∅ 7,9
0
-0,15
3
,1
0
-0
,2
5
min. 0,08
1.1
1.2
1.3
1.4
1.5
1.6
1.7
0 100 200 300 400 500 600 700
Time [h]
V
o
lt
a
g
e
[
V
]
