Mount extension and arm to wall bracket – Omnimount PLAY25X Manual de User Manual
Page 9
9 of 19
888-45-282-W-01 rev.C • 11/12
4
a
+
=
Sleeve
on
Bracket
Rotation
Stop on
Bracket
Slot
in
Sleeve
b
c
Top View
NOTE: when
sliding
sleeve on
to bracket,
align slot
over rota-
tion stop.
Mount extension and arm to wall bracket.
4mm
4mm
M6
M6
M6 x 45mm
M6 x 45mm
Do Not
Overtighten
Cap Screw!
Do Not
Overtighten
Cap Screw!
