6 of 19

888-45-282-W-01 rev.C • 11/12

2

3

4

a

b

c

Wood Stud Mount

c

b

d

Optional locking feature
(customer supplied lock)

2x

CAUTION: Make

sure the wall mount

bracket is level,

fl ush and snug to

the wall surface.

DO NOT OVER-

TIGHTEN

THE BOLTS.

10

2.75”

Ø 3/16" (5mm)

13 mm

Stud Finder
Localizador de largueros de madera
Stud Finder
Auswahl von Montagematerial

Positiebepaler balken
Rilevatore di montanti

スタッド ファインダー
螺栓探测器
스터드 파인더

M8 x 80mm
