Omnimount PLAY25X Manual de - Manual (Page 2)

2 of 19
888-45-282-W-01 rev.C • 11/12
A B C D
1
2
2
1
Ø 3/16" (5mm)
Stud Finder
Localizador de largueros de madera
Stud Finder
Auswahl von Montagematerial
Positiebepaler balken
Rilevatore di montanti
スタッド ファインダー
螺栓探测器
스터드 파인더
Ø 3/8” (10mm)
5°
70°
180°
360°
180°
20"
(508 mm)
25 lbs
(11.3 kg)
0° or 360°
Maximum Screen
Size* = 42”
*Limited to 25 lbs
maximum
13 mm
Wood Stud Mounting Concrete Wall Mounting
