6
Battery Installation Battery Installation Battery Installation Battery Installation Battery Installation
1. Remove the battery compartment
cover located on the bottom of the
balance.
2. Lift out the foam insert.
3. Connect a 9V Alkaline battery to the
battery connector.
4. Replace the foam insert and close
the battery compartment cover.
AC Adapter AC Adapter AC Adapter AC Adapter AC Adapter
Plug the jack from the AC Adapter into
the receptacle located on the right side
of the balance. Plug the AC Adapter into
a convenient ac outlet.
Platform Installation Platform Installation Platform Installation Platform Installation Platform Installation
Install the platform in the top of the
balance as shown in the illustration.
CAUTION: CAUTION: CAUTION: CAUTION: CAUTION: Do not adjust “Down Stop”
screw located next to platform shaft
hole. Screw is factory adjusted.
Press tabs to remove
battery compartment
cover.
