TAJ Carat / Gold Balances EN-3
2.3. Transportation Lock, Calibration Lock & Pan Installation
Before using the balance the Transportation Lock must be released. At the bottom of the
balance slide the locking pin to the position. See Figures 2-1.
If the balance is to be calibrated by the user ensure that the Calibration Lock is set to
position. See Figure 2-2.
Install the metal pan over the plastic sub-platform.
Figure 2-1. Release Transportation Lock. Figure 2-2. Release Calibration Lock.
2.4 Connect Power
A Power Adapter is used to power the balance. Connect the Power Adapter to the power
outlet (see Figure 2-3) and the power plug to the back of the balance (see Figure 2-4).
Figures 2-3. Power Adapter. Figure 2-4. Power Plug.
For use only with UL or CSA Certified
(or equivalent approved) power
adapter, which is a Class 2 or a
Limited Power Source device.
