8) Make sure the grease fittings are covered with the included zerk caps, and that all hardware has
been properly tightened. Remove jack stands from under the vehicle with a jack and you’re
done!
IMPORTANT! Check all hardware after the first five miles. For maintenance, use the zerk fittings to
grease the bushings at least once a year (15,000 miles) or when excessive noise occurs. Use a non-
lithium based grease only. Lithium based grease can wash out with water.
P/N 1213
59-64 Chevrolet B-Body Adj. Rear Upper Arm Kit, Parts List
Hotchkis P/N Item Description
Quantity
Per Kit
1 16410005 Bushing Sleeve, 59-64 Chevrolet B-body 2
2 12910005 Upper Trailing Arm Body, 59-64 Chevrolet B-body 1
3 2438.01 Trailing Arm Bushing, 59-64 Chevrolet B-body 4
4 7/8-14 JAM 7/8" Right Hand Jamb Nut 1
5 7201 Short Zerk Fitting 2
6 12410148 Adjustable Head, 1200 Series 1
7 5/8-18X4HEX 5/8" Hex Head Bolt 2
8 5/8 SAE 5/8" Flat Washer 4
9 5/8-18NYLOCK 5/8" Nylock Nut 2
10 GC-5B Grease Zerk Caps, Black 2
11 9.11108 Grease Pack 1
12 n/a Instruction Set 1
Hardware Included in Kit 1733 (one per kit 1213)
Items Not Shown
