Hotchkis 24366 Mopar B Body Geometry Corrected Sport Leaf Springs User Manual
Hotchkis For the car

Thank you for your purchase from our new line of Mopar parts.
Please call us at 877 - 4NO - ROLL if you have any questions
regarding the service or installation of your Hotchkis Performance products.
IMPORTANT: PLEASE READ THE ENTIRE
STARTING THIS INSTALLATION.
INSTRUCTION MANUAL BEFORE
1.
Raise the Vehicle
Raise the vehicle and safely secure it on jack stands.
2.
Disconnect Rear Shock
Disconnect the lower shock mount nut for each rear shock. You do not have to disconnect the
upper mounts
3.
Disconnect Stock U-Bolts
Disconnect the stock U-bolts that secure the differential tubes to the leaf springs. It is very
common for these u-bolts to be difficult to unfasten. In many cases it is necessary to cut the
u-bolts with a cut-off wheel in order for removal. You Hotchkis kit comes with replacement u-
bolts.
Rear Leaf Spring Kit 24366, 24367
66-70 Chrysler B-body, 70-74 Chrysler E-Body
Document Outline
- Rear Leaf Spring Kit 24366, 24367
- Improperly installed or installed by someone other than a qualified, licensed auto mechanic experienced in the installation and removal of suspension products;
- Improperly serviced, misused, or modified, altered or subjected to abuse, negligence, accident or collision;
- Installed in any vehicle that has been modified;
- Installed on any vehicle that has carried loads in excess of automobile manufacturer suggested weight limits; or
- Installed on any vehicle that has been subject to abnormal or excessive use, including rallying, racing, or racing-type activities or off-road use.
- Did you register the product at 0TUwww.hotchkis.netU0T or via the mail-in warranty card within 30 days of purchase?
- Is the product appropriate to your application?
- Did you carefully and thoroughly read the instructions provided along with the product?
- Do you have the original invoice or sales receipt?
- Is the return date within 36 months from the purchase date?
- Are you the original purchaser?
- Was the product properly installed by a qualified, licensed auto mechanic?
- Has the product been installed on the original vehicle on which it was installed at all times?
- Is the product unmodified and clean?
- Is the reason for return a legitimate product defect?
