Hotchkis 25440R Evo X Heavy Duty Rear End Links User Manual
Installation of hotchkis end links
Thank you for your purchase from our new line of Mitsubishi parts.
Please call us at 877 - 4NO - ROLL if you have any questions
regarding the service or installation of your Hotchkis Performance products.
IMPORTANT: PLEASE READ THE ENTIRE INSTRUCTION MANUAL BEFORE
STARTING THIS INSTALLATION.
1
Raise the Vehicle
Raise the vehicle by using a drive-on alignment rack. Securely block the front wheels of the vehicle. You may also
floor ramps. It is easier to perform this installation with the suspension at normal ride height.
2
Remove Rear End Links
Remove the OE rear end links. You may discard these and the hardware.
3
Install Hotchkis End Links
Follow the diagram on the next page to assemble your end links. There are two different pairs of bolts included in
your kit. One is pair is longer than the other. Use the longer bolts on the sway bar end connection and the shorter
bolts on the control arm mount.
Adjust the length of the end links to the same length as the OE link as an initial setting.
End links use right and left-hand thread heim joints which allow for easy length adjustment without dissassembly.
(Tip: Apply blue thread locking compound to the provided nuts to prolong hardware tightness.)
Rear End Link Kit
25440R
08-up Mitsubishi EVO X
Installation of Hotchkis End Links
Document Outline
- Rear End Link Kit
- 25440R
- Installation of Hotchkis End Links
- Improperly installed or installed by someone other than a qualified, licensed auto mechanic experienced in the installation and removal of suspension products;
- Improperly serviced, misused, or modified, altered or subjected to abuse, negligence, accident or collision;
- Installed in any vehicle that has been modified;
- Installed on any vehicle that has carried loads in excess of automobile manufacturer suggested weight limits; or
- Installed on any vehicle that has been subject to abnormal or excessive use, including rallying, racing, or racing-type activities or off-road use.
- Did you register the product at 0TUwww.hotchkis.netU0T or via the mail-in warranty card within 30 days of purchase?
- Is the product appropriate to your application?
- Did you carefully and thoroughly read the instructions provided along with the product?
- Do you have the original invoice or sales receipt?
- Is the return date within 36 months from the purchase date?
- Are you the original purchaser?
- Was the product properly installed by a qualified, licensed auto mechanic?
- Has the product been installed on the original vehicle on which it was installed at all times?
- Is the product unmodified and clean?
- Is the reason for return a legitimate product defect?
