Hotchkis 2249 2000-2006 GM SUV Sport Sway Bars, Lowered User Manual
Page 4
3.)
Please take note: Some of the GM factory brackets may be bent inwards
from the factory narrow endlinks,(as seen in pic 2) so you may have to use
an adjustable wrench to "tweak" the brackets open to fit the beefier
Hotchkis endlinks
4.)
Lube the sides of the Hotchkis dog-bone style end links.
5.)
Install HP endlinks into the axle brackets, then place The bolt through and
hand tight the nut on. Repeat on other side.
Driver Side
Passenger Side
3
3
4
5
5
