2272 STREET STABILIZER BAR SET
GMC Envoy/Chevy Trailblazer
Thank you for your purchase from our Trailblazer/Envoy Stabilizer Bar set.
Please call us at (877) 4NO-ROLL if you have any questions regarding the service or installation
of your Hotchkis Performance product. Visit us online @ www.hotchkis.net
• This installation will require:
 Hydraulic jack, jack stands, torque wrench
 The following wrenches or sockets: 15mm, 18mm, 21mm
 Allen wrenches or hex sockets: 6mm
INSTALLATION OF HOTCHKIS PERFORMANCE FRONT BAR BUSHING
1) Securely block the rear wheels of the vehicle. Observe the stock front sway bar installation for
reference.
2) Use a 15mm socket and extension to remove the bolts that hold the front bar bushings to the
frame. Retain the hardware for re-installation.
3) Remove the bracket from the bushing. Please note that the bushing is held onto the bracket by
small ‘nubs’ that key into the bracket.
4) Remove the stock bushing from the bar.
5) Grease the inside surface of the new Hotchkis bushing and install onto the bar. Make sure you
place the bushing so the split will face the front of the vehicle. This is for better durability of the
bushing.
6) Reinstall the bracket and tighten the bracket bolts to 45-50 ft-lbs.
7) Re-check all attaching hardware for tightness after driving.
