Hotchkis 81001 Chassis, Max Convertible Set, 67-69 Camaro-Firebird F-Body User Manual
Hotchkis For the car
1967-1969 GM F Body
Hotchkis Performance LLC.
1
1967-1969 GM F-Body Convertible
1404 Center X-Brace Installation Instructions
Thank you for your purchase of this Hotchkis Performance product. Your X-Brace was
designed with the performance and durability you’ve come to expect from Hotchkis
Performance. This lower profile brace will allow you to run larger exhaust piping while still
bracing the center section of your convertible chassis.
Note: Please read the entire installation instructions before starting. Having the right tools will
ensure a smooth install process.
X-BRACE INSTALLATION
1
Jack the vehicle up and support it on jack stands.
2
Creep underneath the car and locate the stock X-Brace and remove it by undoing the 6
bolts that secure it. You may discard the brace and hardware.
