Installation Instructions:
1. Place jack under center of RUV front end and lift until front wheels clear the
ground. Be careful to support the RUV properly so that it is securely supported
but so that Control Arms and shocks can droop to full extension.
2. Remove front wheels.
3. Remove lower Control Arm from the RUV.
4. Remove the bushings, sleeves, and ball joints from the stock control arms. You
will need to reuse these in the new forward Control Arm kit.
5. Now reinstall the bushings, sleeves, and ball joints into the new arms. If you
place some grease on them it makes the installations easier.
