Front installation diagram – High Lifter Lift Kit for Polaris Sportsman 700 User Manual
Page 3
Bracket A-2
Bracket B-2
Front Installation Diagram
OEM
Shock
Bracket “B”
OEM
Shock
Mount
Bracket “A”
Note:
I have left out the Progressive Spring Kit; please follow those instructions for installation. This is how the
lift kit will fit without the Progressive Spring Kit installed. The Progressive collar will go on top of
Bracket “B”.
