1. Remove vacuum slide from carb. Remove stock needle & spacers, noting order of assembly.
2. Using the drill provided (#37) enlarge your stock slide lift hole.
3. Install Dynojet needle on groove #3 for applications below 5000 feet, groove #2 for above 5000 feet, using all stock spacers. Install the Dynojet
washers above the E-clip.
4. Remove stock main jet and replace with Dynojet main provided. Use the DJ134 below 3000 feet, DJ130 from 3000 to 6000 feet and DJ126
above 6000 feet. If you are running an aftermarket exhaust, use the DJ138 below 3000 feet, DJ134 from 3000 to 6000 feet and the DJ130
above 6000 feet. Be sure that the jet you are changing is the main jet.
5. Locate the Fuel Mixture Plug(Fig. B), using a flat blade screwdriver carefully turn mixture screw clockwise until seated, then back out 2-1/2
turns.
Q202.001
STAGE ONE INSTRUCTIONS
Fig. B
Fig. A
This is groove #1
Mixture Screw
Location.
