Parts and their functions
TO PAN/TILT HEAD 2 to 5 terminal
• Functions as the pan/tilt head’s connection terminals 2 to 5 when EXT CONTROL OUT
is set to OFF on the EXTERNAL CONTROL OUT setting (see page 24).
Connect a 10BASE-T straight cable (equivalent to UTP category 5) to the pan/tilt
head’s IP/RP terminal.
May be extended up to a maximum of 1,000 m.
Use the RS-232C/RS-422 converter and connect to pan/tilt head’s RS-232C control
terminal when connecting to the AW-PH300, AW-PH300A, AW-PH500 or AW-PH600.
• Cannot be used when the EXT CONTROL OUT is set to ON on the EXTERNAL
CONTROL OUT setting (see page 24).
MONITOR SELECT terminal
Connect a 10BASE-T straight cable (equivalent to UTP category 5) to the AW-RC400
cable compensation unit’s MONI SEL IN terminal. May be extended up to a maximum of
50 m.
The video signal from the pan/tilt head system connected to the input terminal, whose
number is selected on this unit, will be sent from the AW-RC400’s MONITOR 1, 2
terminals.
