High Lifter DynoJet Jet Kit for Polaris Scrambler (98-09) - Manual (Page 2)

STAGE ONE INSTRUCTIONS
1. Remove vacuum slide from the carb. Remove stock needles & spacers, noting order of assembly (Fig. A).
2. Install Dynojet needle on groove #3 for applications below 3000 feet, groove #2 for above 3000 feet, using
all stock spacers. Install the Dynojet washer above the E-clip.
3. Install the Dynojet slide spring provided (DSP007) in place of the stock slide spring.
4. Remove stock main jet. If you are running the stock exhaust use the DJ150 below 3000 feet, DJ146 from
3000 to 6000 feet and DJ142 above 6000 feet. If you are running an aftermarket exhaust, use the DJ155
below 3000 feet, DJ150 from 3000 to 6000 feet and DJ146 above 6000 feet. Be sure that the jet you are
changing is the main jet.
5. Locate the Fuel Mixture Screw (Fig.B). Using a flat blade screwdriver, turn the mixture screw clockwise
until it seats, then turn out 4 turns below 3000 feet or 3 1/2 above 3000 feet.
Fig.A
Q504.001
This is Groove # 1
Fig.B
Dynojet Parts
Stock Parts
