Design for particle board and mdf board – Hafele EN 372.64 Series User Manual
Page 7
7
64
64
32
32
4
1
4
1
4
1
4
1
)*
2
)*
2
2
3
D
2
3
D
13,5
13,5
Only mark and punch for Ø 4 mm x 8 deep wood screws
or for euro screws according to the drilling pattern.
Inside edge of side wall
Upper edge of base
View of flap supports on the
reverse side of the flap.
View of central hinge joints on the
reverse side of the flap.
For a flap width of 900 mm upwards
we recommend 3 central hinge joints.
Number of drilled holes and
drilling diagram for hinge joint as
per manufacturer’s specification.
16
16
16
16
Ш5
Ш5
*) = in case of adjustable central hinge joints 2-4 mm
4
Drill holes for the cabinet flap which comes in 2 parts
according to the drilling diagram.
Design for particle board and MDF board.
