Hafele EN 372.64 Series User Manual
Page 3
3
Design for aluminum frame profile.
Design for particle board and MDF board.
K
min. 138
13.5
31
0
2
5
50
2
3
D
*
)
)*
*
2
R
*
)
1
Overview on construction sizes
Cabinet height 520 mm - 800 mm
*) =
Fitting and fixing brackets can be positioned
upwards/downwards but in same mm steps.
Width depending on K (Please check!).
**) =
in case of adjustable central hinge joints 2-4 mm
