Xedio Version 4.2 - User Manual – Xedio Playout Organizer
EVS Broadcast Equipment – June 2012
Issue 4.2.B
17
V
IEW
W
INDOW
When you right-click on the playlist item and select View/adjust item, the View
window opens:
User interface items specific to this window are described below.
User Interface
Element
Description
Loads the first frame of the original playlist element.
Loads the last frame of the original playlist element.
Media Bar The Media Bar is the graphical representation of the
displayed clip within the entire media the clip belongs to.
Media bar when the clip is loaded on its first frame. This
is the view displayed when the View window is opened.
Media bar when the clip is loaded on its last frame.
Entire media bar when the first frame of the original
media is loaded (Go to Start of Media).
(colored)
Moves the IN point 1 frame ahead
