EVS XTAccess Version 1.17 - May 2012 User Manual - Manual (Page 29)

XTAccess Version 1.17 – User Manual
EVS Broadcast Equipment – May 2012
Issue 1.17.C
21
7.3 Creation of a XML Jobs Scan
7.3.1 Creating a New XML Scan
On the XTAccess GUI, select the New XML Scan button to create a new scan session
for XML jobs:
The following window is displayed:
Point to the folder where XTAccess will check for XML jobs, and click Start after you have
checked the XML Scan settings.
7.3.2 XML Scan Dialog Box
Field/Button Description
Title Bar
XML Scan[1] –0/6
The Title Bar specifies the ID of Scan XML Jobs folder.
It also displays the number of running jobs vs. the max. running
jobs allowed for this scan folder.
XML Root Folder to be scanned by XTAccess. This folder can be entered
manually or selected using Windows Explorer with the
associated button.
By default, the scan folder is C:\XTAccess_XML\. XTAccess
automatically creates this folder during the XTAccess
installation process.
XML Scan Settings This button is used to display the scan XML Job settings. Those
settings are the default settings of this XML Jobs scan.
The XML file generated to trigger an XTAccess job replaces the
General Settings (see section 9.3 ‘Local XTAccess Settings
(non XML) on page 47) and XML Jobs default settings by its
own values. This means the default settings are only used in
case the XML file triggering the job does not contain the
specific tag.
OPEN This button is used to open the XML Root folder.
