Issue 4.2.B

Xedio Suite Version 4.2 – User Manual – Xedio Importer

EVS Broadcast Equipment –June 2012

24

The following table describes the fields

Field

Description

Label (mandatory)

Name assigned to the files when they are imported to the

Xedio database.

First File

The Browse button allows the selection of one file from

the sequence to be imported.

Files found

Number of files found in the same folder as the selected

first file. You need to have an even number of .tiff files to

import for your RTD sequence.

Video Standard

Video standard to apply to create the transition:
PAL SD, HD 1080i @50, HD 720p @50, HD 1080p @50,

NTSC drop SD, HD 1080i @59,94, HD 720p @59,94, HD

1080p @59.94

Preview Button

Displays the corresponding pictures in the Bitmap,

Bitmap Key and Transition Key fields and then converts

the sequence to display it in the Result field.
