Weight Power BTU
# power
sockets
Hardware CPU RAM Hard Disk
11 kg 320
Watts 1093
BTU/h 2 XT Access
I7 HP Intel I7
950 4GB 2x 250GB
(RAID1)
Cisco Catalyst Ethernet Switch
Connects the various network devices. Series: 3750-E or 3750-X.
Weight Power BTU # power sockets
10 kg 212 Watts 1023 BTU/h 2
Third Party HSM System
IP2Archive can be used in combination with the following HSM systems:
• Front Porch Digital DIVArchive
• XenData Digital Archive
See the websites of the manufacturers for the functional and technical specifications.
Third Party LTO Tape Library
If EVS may supply the LTO tape library, then it will be a tape library by Spectralogic. If the
LTO tape library is not supplied by EVS, then only the HSM software is supported. The
following Spectralogic LTO tape libraries are supported:
• T50e
• T120
• T200
T50e
• Technical specifications: see www.spectralogic.com.
• Capacity and throughput
Media Max Drives Max Slots/Tapes Max Capacity Max Throughput
LTO-6 4 50 400 TB 7.5 TB/h
LTO-5 4 50 150 TB 4.0 TB/h
T120
• Technical specifications: see www.spectralogic.com.
• Capacity and throughput
