(all specifications +/- 5% unless otherwise stated) SPECIFICATIONS:
Input Impedance: 1 Megohm
Bypass: Low noise class A, low source impedance,
operational amplifier driver
Signal To Noise: >102 dB A weighted
Output: <1 Kohm
Frequency Range: Range
Switch Heel Down Toe
FINE TUNE MAX FINE TUNE MIN
1 440 Hz 2.2Khz 1.5Khz
2 400 Hz 1.9Khz 1.3Khz
2 375 Hz 1.8Khz 1.2Khz
4 345 Hz 1.6Khz 1.0Khz
5 295 Hz 1.4Khz .75Khz
6 250 Hz 1.2Khz 1.2Khz
Gain: At center frequencies of bandpass, ~ +15dB +/-
10%, Q @ maximum, without boost
Boost: Boost range relative to no boost, +. 1dB
minimum to +17 dB, +/- 5%
Switching: Noise free controlled by Carlingswitch
Power Requirements: +9 VDC @ <2.5 milliamps, 5.5 mm x 2.1 mm
positive barrel & negative center or
standard 9 Volt battery.
