Parts List
Ref. No. Qty.
Part No.
Description
1 1 61-6080 ..........................................................Wldm't, Deck, SC2100/SC2101
2 2 61-6073 .........................................................................Wldm't, Deck Support
3 2 61-6118 ........................................................................Wldm't, Bracket, Ramp
4 1 61-6077 .......................................Wldm't, Hold Up Bracket, Center Extension
5 1 61-6048 ................................................................... Wldm't, Center Extension
6 1 61-6092 ................................................................................ Wldm't, Tire Stop
7 2 299-0373 .................................................................................Wldm't, Pin, ZP
8 1 SC9000 ..................................................................................... Receiver Hitch
9 1 229-0684 ................................................................................. Ramp, 1500 lb.
10 2 200-1701 ...............................................................Pin, 5/8" x 4" eff. w/clip, ZP
11 4 200-1483 ...............................................................Pin, 5/8" x 3" eff. w/clip, ZP
12 3 229-0520 ..................................................................Pin, 1/2" x 2 5/8" eff. , ZP
13 3 84-0001 ............................................................................Quick Pin Assembly
14 2 62-3458 ............................................................................. Assy, Hair Pin Clip,
15 2 61-6135 ....................................................................Wldm't,Adjuster, SC2100
16 2 201-0323 ........................... 1/2-13 X 1 3/4" Square Head Cap Knrl Set Screw
17 2 201-0011 ..........................................1/2-13 x 1 1/4" Hex Head Bolt, Grd.5, ZP
18 4 201-0008 ................................. 3/8-16 x 1 1/4" Carriage Head Bolt, Grd.5, ZP
19 4 201-0278 ...............................3/8-16 x 3/4" Square Head Cap Knrl, Grd.5, ZP
20 2 202-0073 ...................................................... 5/8-11 Hex Flange Whiz Nut, ZP
21 2 202-0072 ......................................................1/2-13 Hex Flange Whiz Nut, ZP
22 4 202-0003 ...........................................................................3/8-16 Hex Nut, ZP
23 2 203-0012 .........................................................................1/2" Lockwasher, ZP
24 4 203-0010 .......................................................................... 3/8 Lockwasher, ZP
25 2 102-6593 .....................................................................................Flat, Tirestop
SC2100 With all Optional Accessories Installed
