Automatic Equipment Mfg. Co.
One Mill Road, Industrial Park l Pender, Nebraska 68047
292-1190 7/96
© 1994 Automatic Equipment
Mfg. Co. Pender, NE 68047
BX4322
Rangefinder II Tow Bar
Class III (5000 lb) 2 Inch Coupler
QUICK REFERENCE GUIDE
HOOKING UP & EXTENDING FOR TOWING
1. Align vehicles in towing position with straight driveway
ahead and parking brakes locked.
2. Unfold tow bar and latch cross brace latch.
Place ball coupler on 2 inch ball.
3. Drive towing vehicle forward until both legs are locked.
(Latch is locked when rubber seal is not exposed.)
4. Install safety cables and towed vehicle lighting.
5. Detailed instructions appear on pages 2-3.
UNHOOKING & FOLDING FOR STORAGE
1. Park vehicles in a straight line on level surface. Apply
towing vehicle parking brake. Place towed vehicle in
park or 1st gear for manual transmissions.
2. Remove safety cables and towed vehicle lighting.
3. Disengage leg latches. Remove coupler from ball.
Place coupler ring on storage post and pin in place.
4. Detailed instructions appear on page 2-3.
Product Safety Policy Statement
It is, and shall continue to be, a primary objective of Automatic Equipment Manufacturing
Company to provide customers with safe and reliable products. Automatic will, and has, estab-
lished safety procedures in product design, manufacture, promotion and sales; and will coordinate
efforts to promote customer safety to the greatest extent possible. Each department has primary
responsibility for the promotion of safety under the guidelines of the Product Safety Committee.
Repair parts may be ordered through your nearest
Automatic dealer or distributor.
TO BE VALID, THE WARRANTY CARD MUST BE
COMPLETED IN ITS ENTIRETY BY AN AUTHORIZED
DISTRIBUTOR OR DEALER AND SENT TO AUTOMATIC
EQUIPMENT MFG. CO., PENDER, NEBRASKA. FAILURE
TO DO SO WILL VOID THE WARRANTY.
