13 Installation and Startup |
Installing the Battery Tray
NOTE: A small amount of arcing may occur when connecting the batteries. This is normal and does not damage
the unit or present any safety concern.
10 Remove the right battery connector from the door and connect the internal battery connector.
11 Close the metal battery cover.
Adjust the battery connector so that the door closes properly. Push the door slightly to the right
and then to left.
12 Tighten the thumbscrew.
Torque the screw to 0.7 Nm (6.2 lb in).
