Dell Latitude D430 - Manual (Page 21)

Media Base Setup Guide 19
Specifications
Physical
Height 12.8 mm (0.50 inches)
Width 292 mm (11.5 inches)
Depth 207 mm (8.15 inches)
Weight (without a drive in the module bay) 0.61 kg (1.35 lb)
AC Adapter
Input voltage 100–240 VAC
Input current (maximum) 1.5 A
Input frequency 50–60 Hz
Output current (maximum) 3.34 A (65-W AC adapter)
4.62 A (90-W AC adapter)
Output power 65 W
90W
Rated output voltage 19.5 VDC
Dimensions and weight (65-W AC adapter):
Height 28.3 mm (1.11 inches)
Width 57.8 mm (2.28 inches)
Depth 137.2 mm (5.40 inches)
Weight (with cables) 0.36 kg (.79 lb)
Dimensions and weight (90-W AC adapter):
Height 34.2 mm (1.35 inches)
Width 60.9 mm (2.39 inches)
Depth 153.42 mm (6.04 inches)
Weight (with cables) 0.46 kg (1.01 lb)
Temperature range:
Operating 0° to 35°C (32° to 95°F)
Storage –40° to 60°C (–40° to 140°F)
