Media Base Setup Guide
19
Specifications
Physical
Height
12.8 mm (0.50 inches)
Width
292 mm (11.5 inches)
Depth
207 mm (8.15 inches)
Weight (without a drive in the module bay)
0.61 kg (1.35 lb)
AC Adapter
Input voltage
100–240 VAC
Input current (maximum)
1.5 A
Input frequency
50–60 Hz
Output current (maximum)
3.34 A (65-W AC adapter)
4.62 A (90-W AC adapter)
Output power
65 W
90W
Rated output voltage
19.5 VDC
Dimensions and weight (65-W AC adapter):
Height
28.3 mm (1.11 inches)
Width
57.8 mm (2.28 inches)
Depth
137.2 mm (5.40 inches)
Weight (with cables)
0.36 kg (.79 lb)
Dimensions and weight (90-W AC adapter):
Height
34.2 mm (1.35 inches)
Width
60.9 mm (2.39 inches)
Depth
153.42 mm (6.04 inches)
Weight (with cables)
0.46 kg (1.01 lb)
Temperature range:
Operating
0° to 35°C (32° to 95°F)
Storage
–40° to 60°C (–40° to 140°F)
