Dell UPS 4200R User Manual
Page 55
53
Installation und Inbetriebnahme
|
Kommunikationssteckplatz
der USV
Eingangsklemmen
USB-Anschluss
Sechs IEC 320-C13-Anschlussdosen
(Lastsegment 2)
REPO-Schnittstellen
RS-232-Schnittstelle
Erdungsschraube
Vier IEC 320-C19-Anschlussdosen
(Lastsegment 1)
EBM-Anschluss
Ausgangsüberlastschalter
Abbildung 5. Rückwärtige Anschlussleiste für 4200W, 230V
