Dell UPS 5600R User Manual
Page 90
88
|
Instalación y arranque
Seis receptáculos
IEC 320-C13
(Segmento de carga 2)
Puertos
REPO
Cuatro receptáculos de IEC 320-C19
(Segmento de carga 1)
Conector EBM
Dos interruptores del circuito de salida
Compartimiento
de comunicación
del UPS
Puerto USB
Puerto
RS-232
Bloque terminal de
entrada
Tornillo con
conexión a
tierra
Interruptor del
circuito de salida
Figura 19. Panel posterior del 5600W, 230V
